CA$30,000
Generally in audio designs simple circuits tend to work, and most important, sound much better
|
Full swing signal bandwidth: |
-6db @ 4Hz~140kHz |
|
Maximum signal output swing: |
32Vrms @ 10kohm load -6db switch |
|
Gain: |
Reconfigurable step down – 20db/14db selectable |
|
Tube list: |
2 x E280F, 1 x 5AR4 (rectifier) |
|
Harmonic distortion: |
0.005% typical |
|
Maximum harmonic distortion: |
Less than 0.1% THD at 20V rms |
|
Inputs: |
5 x RCA pairs, 1 x Balanced pair, 1 x AC link proprietary input |
|
Output impedance: |
<50ohm (12ohm in -6db mode) |
|
Tube Bias: |
Adjustable bias on the fly |
|
User readouts: |
Online dual channel bias monitor |
|
Supplied accessories: |
External power supply unit, metal remote control |
|
Weight: |
34kg unpacked |
