QUALITION
PHONO Preamplifier

CA$5,115

Description ▴

Meet the next evolution in our reference phono preamplifier design: the all-new Qualiton Phono! Building on the legacy of its predecessor, we’ve completely redesigned the MM preamplifier, drawing inspiration from the much-loved MM circuits of our C200 preamplifier. With the addition of 6SL7GT tubes, we’ve not only refined the sound character but also elevated the aesthetics to new heights. It now comes with an integrated MC step-up transformer by default, and its footprint is more compact, thanks to the sophisticated layout design.

Product Specifications ▾



 Nominal output level- Line 700 mV
 Input sensitivity- Phono (MM) 5mV, to nominal output level
 Input sensitivity- Phono (MC Hi- Z) 0,4 mV, to nominal output level
 Input sensitivity- Phono (MC Lo- Z) 0,3 mV, to nominal output level
 Max. input signal- Phono (MM) 120 mV
 Gain- Phono (MM) +43 dB
 Gain- Phono (MC Hi- Z) +65 dB
 Gain- Phono (MC Lo- Z) +68 dB
 Frequency response- Phono (MM) 20 Hz- 20kHz, (-0,5 dB)
Recommended MCcartridge internal
impedance- Phono (MC Hi-Z)
 10- 40 Ohm
 Recommended MCcartridge internal
impedance- Phono (MC Lo-Z)
 2- 10 Ohm
 Signal-to-noise ratio- Phono (MM) > 70dB(with tube cover)
 Number of input ports 2 PHONOlevel input
 Number of output ports 1 unbalanced line level output (LINE)
 Tubes required 4 x6SL7GT
 Weight 8 kg
 Dimensions 24 x 34x16cm
