Description ▴

The L-507z joins Luxman’s integrated amplifier range with numerous advances and features our newly designed “LIFES1.0” distortion canceling feedback engine. “LIFES” is a significant evolution from “ODNF” circuitry, which has long been a key advantage of Luxman amplifiers since its 2010 introduction in our X-series. The robust L-507z marks the beginning of Z-Series, all being developed to include this latest “LIFES” high-quality amplification system, a core technology also shared with our new flagship M-10x stereo/mono power amplifier.

Product Specifications ▾

Rated output 110W + 110W (8Ω) 220W + 220W (4Ω)
Input sensitivity/input impedance PHONO (MM): 2.5mV / 47kΩ PHONO (MC): 0.3mV / 100Ω LINE: 180mV /47kΩ BAL.LINE: 180mV / 79kΩ MAIN-IN: 1.05V / 47kΩ
Output voltage PRE OUT: 1V
Frequency response PHONO: 20Hz to 20kHz (within ± 0.5dB ) LINE: 20Hz to 100kHz (within -3.0dB)
Total harmonic distortion 0.007% or less (8Ω, 1kHz) 0.03% or less (8Ω, 20Hz to 20kHz)
LINE 105 dB or more
Volume control New LECUA 1000
Amplification circuit LIFES 1.0
Output configuration Bipolar 3 parallel push-pull
Power transformer EI type 560VA
Damping factor 300 (by EIAJ current injection method)
Tone control BASS: ± 8dB at 100Hz TREBLE: ± 8dB at 10kHz
Power-supply voltage AC110V (50 / 60Hz)
Power consumption 300W / 86W (no signal ) 0.4W (standby)
External dimensions WxDxH 17 1/4 x 7 1/16 x 17 7/8″ 440mm x 454mm x 178 mm
Weight 25.4kg (main body), 29.4kg (standard packaging)
