AURENDER
AP20

$30,800.00

Description ▴

If ever Aristotle’s adage: “the whole is greater than the sum of its parts” is applicable in audio, it applies to AP20. And, given the quality and quantity of parts in this equation, that’s saying a lot.

AP20 delivers unprecedented audio performance from an integrated amplifier. It includes the world’s best Class D amp modules in a dual-mono configuration, an analog R2R relay-based volume control and preamp section, Aurender’s best DAC, a master clock input, a headphone output, a suite of digital and analog inputs and outputs, and the most sophisticated linear power supply block Aurender has ever deployed.

The result? An audio component that paints every musical timbre with full-bodied realism. With a delicate touch that’s backed up by enormous headroom for transients and dynamic swings, AP20 drives even the most demanding speaker loads and casts a soundstage that is both expansive and laser-focused.

Product Specifications ▾

Power Supply Full Linear, 2x 400VA Toroidy Transformers (L&R Power Amp), 2x 50W (L&R Audio Boards), 1x50W (CPU), 1x25W (FPGA)
CPU Intel Low Power Quad Core
RAM 8GB
Library Storage Capacity 2X 2.5″ Compartments (User-Installable Storage)
SSD for System & Cache 480GB NVME
Data USB Ports 2X USB 3.0 (Rear)
Material Machined Aluminum Chassis
Front Panel Display 8.8″ 1920 x 480 Wide IPS Color LCD
Volume Control Relay-Based R2R Stereo Attenuator -64dB ~ 0dB., Velocity Sensitive Operation
Analog Outputs XLR (Balanced)
Analog Inputs 2 x Unbalanced (RCA)/1x Balanced (XLR)
Audio Word Clock OCXO Rev2
Analog Outputs Supported Format PCM: Up to 32-bit / 768 kHz; DSD: Up to DSD512
Digital Inputs 1X Coax RCA, 1X Coax BNC, 2X Optical/Toslink
Amplifier Module 2x Purifi 1ET400A Class D Amplifier Module in Dual-Mono Configuration
Rated Output Power 200 W into 8 ohms / 350 W into 4 ohms
THD (20Hz-20kHz) 0.003 % (1W to 200 W, 8 ohms and 4 ohms)
Damping Factor 800 (ref. 8Ω 20 Hz to 6.5 kHz)
Output Impedance <65μΩ @ 1kHz
Dimensions 16.93″W x 14.2″D x 5.9″H
Weight 57.3 lb
