Technology:

Single stage, Single Ended, TriodeFet technology

Gain stages:

Single stage amplifier, from input to output posts

Power output:

35W @8ohms

Tube compliment:

2 x E280F / E282F / E810F / E180F

Volume control:

26 step TVC volume control technology

Inputs:

4 X RCA , 1 X XLR (pin 2 used), 1 x Direct (Ac link)

Power bandwidth:

full power at 5Hz -3db

Maximum gain:

21db (tube dependent)

Noise floor:

-90db ref 1V RMS

Dimensions:

Main unit: 420mm W x 310mm D X 420mm H 80kg

PSU unit: 420mm W x 310mm D x 140mm H 35kg
