Technical Specifications
Analog Inputs | 3 pairs XLR, 2 pairs RCA |
Analog Outputs | 2 pairs XLR (1 as standard and P-LINK) |
Voltage gain | +8db (2) |
Maximum input level | (+17dbu) 5,6Vrms XLR, (+11 dbu) 2,8Vrms RCA |
Input Impedance balanced (XLR) | 60 KΩ |
Input Impedance single ended (RCA) | 30 KΩ |
Output Impedance | < 10 Ω |
Frequency Response | (-3dB) 0.1Hz – 500kHz |
THD + N | 0.0172% @ 1kHz |
Signal to Noise | 119db |
General Specifications
Display | TFT 5′ 800×480 LED 16.7M |
Power Consumption (Standby) | 10.5W |
Power Consumption (Operation) | 17W |
Dimensions (Preamp Unit) | W480 x D490 x H212 (mm) |
Dimensions (PSU Unit) x 2 | W235 x D490 x H162 (mm) |
Net Weight (Preamp Unit) | 52kg |
Net Weight (PSU Unit) | 19.5kg/Unit (39kg Total) |
Shipping Weight | 110kg |
